skEYEwatch X3 Core
X3 Core - More Than Just an mDVR
Everything you ever need to know about our skEYEwatch X3 Core is right here. The skEYEwatch X3 Core is a rugged piece of powerful technology that is installed in vehicle fleets to track anything you can possibly think of about your fleet assets. It powers our GPS fleet tracking technology (skEYEtrax), pulls data from custom sensors, telematics data, and it’s the mobile digital video recorder (mDVR) for our vehicle & truck camera system.
Photos, specs, user manual and more.
4G/LTE Wireless Connection
4G/EVDO/WCDMA/TDD-LTE/FDD-LTE : Used for live view and remote management. View your vehicle cameras and mDVR surveillance in real time from anywhere as long as you have an internet connection.
8 Channel mDVR
8 CH (AHD*6+IPC*2 ) : The X3 Core supports up to 6 audio/video channels + 2 IPC channels (video only).
H.265/H.264 Compatible
H.265/H.264 encoding and decoding to improve the memory space utilization
GPS for location tracking
The X3 comes with GPS tracking and reporting capabilities. This allows admins to view their fleet vehicles on a digital map in real time. It also records breadcrumb history of past trips as well as GPS longitude latitude and vehicles driving speed.
The skEYEwatch X3 Core is also compatible with advanced telematics and sensor tracking. This allows admins to generate specialized reports such as off route reports, unauthorized stops, fuel usage, and more.
Wireless Camera Compatibility
Our X3 mDVR is compatible with some of the latest wireless camera solutions.
FAQs
FAQs About The skEYEwatch X3 Core.
Why won't my skEYEwatch X3 Core power on?
Usually this problem results from the incorrect power connection. Please follow below steps to check the power connection:
Check the input power, whether the power wire is connected correctly, whether the ground wire
is connected back to the battery, and whether the fuse on the power wire is in good condition.
Check whether the ACC signal wire input to the power is with voltage higher than 7 V.
Check whether the device key is closed.
Why does the X3 mDVR restart uninterruptedly?
Please follow below steps to check it:
Check whether the voltage of MDVR is insufficient. If the voltage is less than the start-up
voltage of the device, the device would always restart.
The problem in hard disk/SD card may cause the failure to start. Take off the storage part and
check whether it is broken down.
Why won't the skEYEwatch X3 mDVR record video surveillance?
Usually this problem results from the storage disk or camera. Please follow below steps to check it:
- Check whether the storage disk is installed, whether it is in good contact, and whether the disk can be read normally in computer.
- Check whether the storage disk is formatted. The storage disk should be formatted before normally storing record files.
- Check whether there is video signal input into the device from camera, and whether there is video/image on the screen.
There is no audio in record file. Why can't I hear audio on my X3 mDVR?
Please follow below steps to check it:
Check whether there is an external pickup, or whether the camera features with the function of audio collection.
Access to Video Channel Settings, check if Audio is set on.
There must be video input into the channel for recording and it must record normally.
Why isn't the GPS tracking my fleet?
Please follow below steps to check it:
Check whether the GPS antenna is installed correctly. There is a silk print logo on the GPS
antenna holder behind the host device.
Check whether the antenna receiver is sheltered. It should not be covered by any stuff, which
may cause it not to receive signals.
Environmental influence such as tree shades, being inside tunnel, driving near tall building or elevated roads, thunderstorms or other weather influence, etc. can also cause signal loss or receiving wrong signals.
Why won't the skEYEwatch X3 Core shut down in ignition switch mode?
- Check if the ACC line connection mode is correct; and check whether there is voltage on ACC yellow line when the key is turned off.
- If the device has been set with schedule recording, it can’t shut down if it is still during recording time of the task table.
skEYEwatch X3 Core schematics
